SKU: K-350FC
Noise-less (69dB). Oil free, Copper wire motor. Horse power: 3HP. Speed: 2850RPM. Tank: 50 litres. Gauge for tank pressure. Max Delivery: 440L/min. Max Pressure: 8Bar/16Psi, Reset button. Pressure reducer with gauge. Rubber grip handle. Vulcanized rubber feet for stable position. Weight: 36.5 kgs.
₹ 0/-
Blow Up
Spares
. | TOOL MODEL | K-350FC | REV.1ST APRIL 23 | |||||||
SR | FMS | PART CODE | PART NAME | ALT CODE | SR | FMS | PART CODE | PART NAME | ALT CODE | |
1 | K350FC001 | COVER | K110FC001 | 34 | K350FC034 | HEXAGON NUT | K110FC030 | |||
2 | K350FC002 | LEFT FAN | K110FC002 | 35 | K350FC035 | ELBOW | K110FC034 | |||
3 | K350FC003 | CRANKSHAFT | K124FC003 | 36 | K350FC036 | TANK | ||||
4 | K350FC004 | HEXAGON SOCKET SCREW | K124FC004 | 37 | K350FC037 | WIRED HOSE | K110FC035 | |||
5 | K350FC005 | CONNECTING ROD | K110FC005 | 38 | K350FC038 | CHECK VALVE | K110FC037 | |||
6 | K350FC006 | PISTON CUP | K110FC006 | 39 | K350FC039 | SOLENOID VALVE | ||||
7 | K350FC007 | PRESSING PLATE | K110FC007 | 40 | K350FC040 | HEX NUT | K124FC047 | |||
8 | K350FC008 | CROSS RECESS HEAD SCREW | K110FC008 | 41 | K350FC041 | RUBBER | K124FC040 | |||
9 | K350FC009 | CYLINDER | K110FC009 | 42 | K350FC042 | FLAT GASKET | ||||
10 | K350FC010 | LEFT BOX BODY | K110FC010 | 43 | K350FC043 | HEXAGON BOLT | ||||
11 | K350FC011 | SEAL GASKET FOR CYLINDER | K110FC011 | 44 | K350FC044 | DRAIN VALVE | K110FC051 | |||
12 | K350FC012 | VALVE PLATE | K110FC012 | 45 | K350FC045 | AXLE | K124FC044 | |||
13 | K350FC013 | CYLINDER HEAD GASKET | K110FC013 | 46 | K350FC046 | IDLER WHEEL | K124FC045 | |||
14 | K350FC014 | CYLINDER HEAD | K110FC014 | 47 | K350FC047 | SPRING WASHER | K124FC046 | |||
15 | K350FC015 | HEXAGON SOCKET SCREW | K110FC015 | 48 | K350FC048 | HEX NUT | K124FC047 | |||
16 | K350FC016 | CONNECTION ALUMINUM TUBE | K110FC016 | 49 | K350FC049 | PAPER PAD | K124FC050 | |||
17 | K350FC017 | TUBE O-RINGS | K110FC017 | 50 | K350FC050 | SWITCH CONNECTOR | K124FC051 | |||
18 | K350FC018 | CROSS RECESS PAN HEAD SCREW | K110FC018 | 51 | K350FC051 | SWITCH UNION NUT | K124FC052 | |||
19 | K350FC019 | STOP BLOCK | K110FC019 | 52 | K350FC052 | SAFETY VALVE | K110FC037 | |||
20 | K350FC020 | OUT OF THE AIR VALVE SLICE | K110FC020 | 53 | K350FC053 | PRESSURE SWITCH | K124069 | |||
21 | K350FC021 | INTAKE VALVE SLICE | K110FC021 | 54 | K350FC054 | DOUBLE JOINT | K110FC040 | |||
22 | K350FC022 | STRENGTHEN THE GASKET | K110FC022 | 55 | K350FC055 | REGULATOR | ||||
23 | K350FC023 | SOCKET HEAD SCREW | K110FC023 | 56 | K350FC056 | BALL VALVE | ||||
24 | K350FC024 | RIGHT FAN | 57 | K350FC057 | PRESSURE GAGE Y40 | K124072 | ||||
25 | K350FC025 | BEARING | K110FC024 | 58 | K350FC058 | PRESSURE GAGE Y50 | K110FC039 | |||
26 | K350FC026 | THE RIGHT BOX | K110FC025 | 59 | K350FC059 | ELECTRICAL WIRES | K110FC036 | |||
27 | K350FC027 | LEAD SKIRTS | K110FC026 | 60 | K350FC060 | AMPHENOL CONNECTOR O TYPE | ||||
28 | K350FC028 | HEXAGON BOLT | K110FC027 | 61 | K350FC061 | AMPHENOL CONNECTOR U TYPE | ||||
29 | K350FC029 | CROSS PAN HEAD SCREW | 62 | K350FC062 | POWER PLUG | K124FC063 | ||||
30 | K350FC030 | STATOR | K110FC029 | 63 | K350FC063 | CAPACITANCE | K110FC054 | |||
31 | K350FC031 | HEXAGON NUTS | K110FC030 | 64 | K350FC064 | CAPACITANCE BOX | K110FC055 | |||
32 | K350FC032 | ROTOR | K124FC032 | 65 | K350FC065 | CAPACITANCE BOX SCREW | ||||
33 | K350FC033 | CRASH PAD | K110FC032 | 66 | K350FC066 | AIR FILTER | K110FC052 |
