SKU: K-110FC
Noise-less (69dB). Oil free, Copper wire motor. Horse power: 1.5HP. Speed: 2850RPM. Tank:10 Litres. Gauge for tank pressure. Max Delivery: 220L/min. Max Pressure: 8Bar/16Psi, Reset button. Pressure reducer with gauge. Rubber grip handle. Vulcanized rubber feet for stable position. Weight: 15.5 kgs.
₹ 0/-
Blow Up
Spares
| . | TOOL MODEL | K-110FC | REV.1ST APRIL 23 | |||||||
| SR | FMS | PART CODE | PART NAME | ALT CODE | SR | FMS | PART CODE | PART NAME | ALT CODE | |
| 1 | K110FC001 | Cover | 30 | K110FC030 | Hexagon nuts | |||||
| 2 | K110FC002 | Left fan | 31 | K110FC031 | Rotor | K124FC032 | ||||
| 3 | K110FC003 | Crankshaft | K124FC003 | 32 | K110FC032 | Crash pad | ||||
| 4 | K110FC004 | Hexagon socket screw | K124FC004 | 33 | K110FC033 | Hexagon nut | ||||
| 5 | K110FC005 | Connecting rod | 34 | K110FC034 | Elbow | |||||
| 6 | K110FC006 | Piston cup | 35 | K110FC035 | Wired hose | |||||
| 7 | K110FC007 | Pressing plate | 36 | K110FC036 | Electrical wires | |||||
| 8 | K110FC008 | Cross recess head screw | 37 | K110FC037 | Safety valve | |||||
| 9 | K110FC009 | Cylinder | 38 | K110FC038 | Pressure switch | K124069 | ||||
| 10 | K110FC010 | Left box body | 39 | K110FC039 | Y50 pressure gage | |||||
| 11 | K110FC011 | Seal gasket for cylinder | 40 | K110FC040 | 1/4double joint | |||||
| 12 | K110FC012 | Valve plate | 41 | K110FC041 | Y40 pressure gage | K124072 | ||||
| 13 | K110FC013 | Cylinder head gasket | 42 | K110FC042 | Regulator | |||||
| 14 | K110FC014 | Cylinder head | 43 | K110FC043 | Ball valve | |||||
| 15 | K110FC015 | Hexagon socket screw | 44 | K110FC044 | Check valve | |||||
| 16 | K110FC016 | Connection aluminum tube | 45 | K110FC045 | Release pipe | |||||
| 17 | K110FC017 | Tube o-rings | 46 | K110FC046 | Tank | |||||
| 18 | K110FC018 | Cross recess pan head screw | 47 | K110FC047 | Hexagon nut | |||||
| 19 | K110FC019 | Stop block | 48 | K110FC048 | Rubber | |||||
| 20 | K110FC020 | Out of the air valve slice | 49 | K110FC049 | Hexagon nut | |||||
| 21 | K110FC021 | Intake valve slice | 50 | K110FC050 | Power plug | |||||
| 22 | K110FC022 | Strengthen the gasket | 51 | K110FC051 | Drain valve | |||||
| 23 | K110FC023 | Socket head screw | 52 | K110FC052 | Air filter | |||||
| 24 | K110FC024 | Bearing | 53 | K110FC053 | Plastic cover | |||||
| 25 | K110FC025 | The right box | 54 | K110FC054 | Capacitance | |||||
| 26 | K110FC026 | Lead skirts | 55 | K110FC055 | Capacitance box | |||||
| 27 | K110FC027 | Hexagon bolt | 56 | K110FC056 | BRASS AIR BREATHER | |||||
| 28 | K110FC028 | Spring washer | 57 | K110FC057 | Oilfree Motor | |||||
| 29 | K110FC029 | Stator | ||||||||
